Carpenter CAD Software ElementsCAD for Vectorworks

ElementsCAD Update to 2023

21X00X22
€695.00

ElementsCAD - the practical carpenter CAD AddOn with extensive Vectorworks library

ElementsCAD contains over 50 tools and commands for Vectorworks.

In addition, an extensive Vectorworks library is included.

Additional functions (excerpt):

  • Powerful ElementsCAD cabinet module for 3D / 2D furniture
  • Parts lists, CNC export
  • Fittings and drilling patterns of different manufacturers
  • Parametric windows and doors
  • Cut dimensioning, 3D cuts
  • Tools for counters, frames/corner benches, curved furniture
  • Carpenter CAD accessories with over 3 GB 3D materials, symbols, image fills etc...

Product customization

Don't forget to save your customization to be able to add to cart
  • 250 char. max
Elements version
Output version
Quantity
  No hidden fees!

Our prices and charges are displayed in a clear and transparent manner - definitely no hidden costs

  Secure SSL connection

Your connection with our server is encrypted

ElementsCAD - the practical carpenter CAD AddOn with extensive Vectorworks library

ElementsCAD integrates with Vectorworks and enriches the program with over 50 tools and commands.

ElementsCAD accessories include an extensive Vectorworks library.

ElementsCAD comes with working environments for the different Vectorworks versions such as Vectorworks Basic or Vectorworks Architecture.

Functional comparison ElementsCAD XS - PRO

XS PRO
Parametric 3D cabinet *
Parametric 2D cabinet
Configure cabinet, exchange fronts, textures, handles etc.
Assign drilling patterns, component info
Generate parts lists
Import MRegio online cabinet √ *
Export CAM function
√ *
Parametric frames, parametric frames from contour
Parametric counters
Parametric windows, doors, stairs
Parametric walls, compatible with walls of industry versions.
Function create roof / roof area, compatible with roof functions of industry versions
Timber construction functions Beam / Connector etc. with export Hundegger...
General tools: stamps, alignment, search, edit dimension tools etc.
ElementsCAD libraries (approx. 3 GB of symbols, textures, image objects, etc.)
* Highly restricted availability
(for cabinet module only basic furniture with 1 segment for simple furniture possible)

Other ElementsCAD versions

ElementsCAD PRO - ElementsCAD XS - Elements Studi (school, student, lecturer versions) - Elements Demo (30 days trial version)

ElementsCAD Studi and demo versions are fully functional (-> ElementsCAD PRO versions).

Student versions correspond to the same runtime as the Vectorworks student version.

For ElementsCAD student versions, the Export CAM function is disabled for technical reasons.

30-day trial versions are fully functional during the trial period.

ElementsCAD also includes an extensive accessories library. This contains several thousand items such as 3D textures, image fills, symbols, etc.

The accessory libraries are only included in ElementsCAD PRO and ElementsCAD XS, but not in the student and demo versions.

In the Carpenter CAD module ElementsCAD the Vectorworks library includes not only objects from the kitchen, office, living room and bedroom sectors, but also 3D handles from various suppliers, seating furniture and 3D sanitary objects from Villeroy & Boch.

ElementsCAD contains all functions to create photorealistic 3D room designs also with Vectorworks Basic/Fundamentals.

ElementsCAD contains all functions to create photorealistic 3D room plans also with Vectorworks Basic/Fundamentals.

21X00X22

Data sheet

Language
German
Operating system
Mac
Windows

Download

ElementsCAD installation

ElementsCAD installation guide

Download (662.69KB)
